Circular Metal Cutting Bandsaw Machine

Get a Price/Quote

Circular Metal Cutting Bandsaw Machine Specification

Drive Motor
Induction Motor 1 HP

Product Type
Circular Metal Cutting Bandsaw Machine

General Use
Cutting ferrous and non-ferrous bars, pipes, profiles

Material
Metal

Type
Circular Saw Machine

Capacity
Up to 180 mm Dia round, 125x125 mm Square

Weight (kg)
Approx 260 kg

Computerized
No

Automatic
Fully Automatic

Cutting Speed
40-60 m/min (Variable)

Cutting Thickness
Up to 6 mm

Cutting Function
Metal circular cutting

Cooling System
Integrated Water Coolant System

Drive Type
Belt Drive

Voltage
415 V / 50 Hz (Three Phase)

Dimension (L*W*H)
1400 x 620 x 1050 mm

Feature
Robust construction, low vibration, high performance

Color
Industrial Blue & Silver

Motor
1 HP, 1440 RPM Electric Motor

Mechanical Precision
High repeatability, accurate angle cutting

Software Detail
Not Applicable (Manual Machine)

Cutting Method
Circular Saw

Control System
Manual Lever Operation

Cutting Material
Mild Steel, Stainless Steel, Aluminum, Brass

Cutting Area
180 mm (Diameter)

Surface Finish
Powder Coated

Lubrication System
Grease Cup Type

Noise Level
< 75 dB

Coolant Tank Capacity
20 Liters

Blade Size
2450 mm x 27 mm x 0.9 mm

Clamping Method
Manual

Saw Arm Adjustment
Swiveling Arm for Mitre Cuts (Up to 45)

Work Holding
Quick Acting Vice

Operation Mode
Manual Feed (Hydraulic Feed on request)

Standard Accessories
Set of Allen Keys, Work Stopper, Blade, Coolant Pump

Blade Tension Adjustment
Manual Screw Type

Safety Features
Blade guard, Emergency stop switch

Installation Area Required
Approx. 2 m2

Recommended Use
Workshop, Tool Room, Fabrication Shop

Packaging
Wooden Box Packing

Power Consumption
Approx. 1.2 kW

About Circular Metal Cutting Bandsaw Machine

Product details

Operation	Automatic
Cutting Blade Size	14 Inch
Material	steel
Color	Grey,White
Warranty	1 year
Machine Type	circular
Cutting Capacity	20-80 mm
Model Number/Name	100
Brand	Mec Technology
Power Consumption	15 Hp
Usage/Application	Metal Cutting
Model	Circular Saw

Efficient and Precise Cutting

Experience high repeatability and accurate angle cutting on a variety of metals including mild steel, stainless steel, aluminum, and brass. With a cutting capacity of up to 180 mm diameter and a variable speed of 40-60 m/min, this bandsaw offers excellent versatility for both ferrous and non-ferrous materials.

User-Friendly Operation

Designed for ease of use, the machine features manual lever operation, quick-acting vice, and easy blade tension adjustment. The swiveling arm allows for precise mitre cuts, while robust construction guarantees low vibration and optimal safety, even during continuous operations.

Integrated Cooling and Lubrication

An integrated water coolant system paired with a 20-liter tank and grease cup type lubrication ensures smooth operation, reduced wear, and a consistently high-quality surface finish on all cut materials.

FAQ's of Circular Metal Cutting Bandsaw Machine:

Q: How does the quick-acting vice work on this bandsaw machine?

A: The quick-acting vice securely holds the workpiece in place, allowing for swift and repeatable clamping. This manual clamping method enables users to minimize downtime between cuts and maintain workpiece alignment for improved precision.

Q: What materials can this circular bandsaw cut, and what is its maximum cutting capacity?

A: This machine is suitable for cutting various metals, including mild steel, stainless steel, aluminum, and brass. It accommodates round materials up to 180 mm in diameter and square profiles up to 125x125 mm, with cutting thickness up to 6 mm.

Q: When should I use the integrated coolant system, and what benefits does it offer?

A: The integrated water coolant system should be used during all cutting operations to keep the blade cool and reduce heat buildup. This extends blade life, minimizes material deformation, and ensures smoother, cleaner cuts with less burr formation.

Q: Where is this bandsaw best installed for maximum efficiency?

A: The machine is ideal for installation in workshops, tool rooms, and fabrication shops. It requires approximately 2 square meters of space and is packaged in a sturdy wooden box to ensure safe delivery and easy setup.

Q: What are the main benefits of the swiveling arm for mitre cuts?

A: The swiveling arm allows for precise angle adjustments up to 45 mitre cuts. This feature is particularly useful when working with frames or structures requiring angled joints, providing high repeatability and accurate results with minimal setup time.

Q: How do I adjust the blade tension and what maintenance does it require?

A: Blade tension is easily adjusted using the manual screw-type mechanism. Regularly check and maintain blade tension, clean the coolant system, lubricate moving parts with the grease cup, and ensure the blade guard and safety switches are in working order to keep the machine running efficiently.
