MAIN COMPONENT & MAKE
S. No. |
Name |
Make |
1. |
Hydraulic Pump |
Douty / Eaton |
2. |
Hydraulic Valve |
Yuken |
3. |
Hydraulic Cylinders |
MEC |
4. |
Feed Control Valve |
Rexroth |
5. |
Electric Motor |
BBL / Crompton |
6. |
PLC |
Omron |
7. |
HMI 7 |
Omron |
8. |
Sensors |
Siko/Omron |
9. |
Electrical Switchgear (MCB, Contactor, OLR) |
Eaton |
ïFeatures -ï
Stress relieved torsion free fabricated bed cutting arm.
Robust 2-coulmn linear-guided saw frame.
Saw frame guidance by pre-stressed linear guide ways and warp resistant frame construction.
High Efficiency Power Transmission through Worm/ Helical gear box.
Adjustable Dovetail type Heavy duty Movable Blade guide with ball bearing.
Automatic adjustment of saw blade guidance to material width.
Hydraulic Power Pack with easy maintenance & a tank of 60 Ltr. with all control valves, gauges & oil level indicator for easy check and maintenance.ï
Automatic Machine OFF, in case of Blade Breakage.
Double Acting Hydraulic Cylinder for vice Clamping & De-clamping.ïï
Driven saw blade cleaning brush.
Powerful, frequency-controlled saw blade drive.
Rapid lowering of the saw frame via button until material edge by height sensing.
Infinitely variable Feed Control Valve for Setting the Cutting feed & upward movement by hydraulic cylinder.ï
Cycle sequencing thru PLC and user friendly touch screen for easy operation.ï
Electrical control panel with high quality switchgears.
Ergonomically designed control panel.
Color Touch Screen (HMI) 7".
NC Control Version for Job Length Setting.
PLC Control System for machine automatic process.ï
